Applications
1. Suitable for multi-industry coating applications, multiple impositions, high-capacity requirements, large-area selective coating processes with various process technologies;
2. A variety of valve body configurations, various valve body arrangements, to meet the needs of diverse panel production;
3. The equipment has its own spray effect detection function, which can manually detect the spray quality in real time.
Features
1. Greatly improving efficiency and Flexible multi-axis control.
2. Four kinds of valves - can be selected to meet different coating requirements.
3. Strong process control ability - ensure coating quality and consistency.
4. Others, including two-dimensional code, bar code scanning, automatic adjustment and anti-stay program.
|
Specifications |
iCoat-3 |
iCoat-3A |
iCoat-3B |
iCoat-3C |
|||
|
Coating parameters |
Working area (mm) |
X=450 Y=450 Z=100 |
X=200 Y=450 Z=100 |
X=220 Y=450 Z=100 |
X=200 Y=440 Z=100 |
||
|
Maximum components height |
±90 |
||||||
|
PCB Edge Clearance (mm) |
≥ 5 |
||||||
|
Single Spray Width (mm) |
2-30 |
||||||
|
Conveyor Height (mm) |
900±20 |
||||||
|
X, Y Conveyor speed (m/min) |
2-13 |
||||||
|
Operation system |
Number of valve |
Dual valves in a row (fixed width) |
Dual valves + tilt; manual adjustable width |
Four valves in a row + tilt |
Four valves front & back + front & back tilt |
||
|
Maximum moving speed (mm/s) |
800 |
||||||
|
Repeated accuracy |
±0.02 |
||||||
|
Facility parameters |
Dimensions (mm) |
L=900 W=1300 H=1675 |
|||||
|
Weight (kg) |
530 |
||||||
|
Required Air Supply (Mpa) |
≥ 0.4 |
||||||
|
Exhaust air volume (m3/min) |
15 |
||||||
|
Control and operation system |
Control |
Integrated microprocessor controllers |
|||||
|
Software |
Anda software with Window OS |
||||||
|
Programming |
Keyboard / mouse mode |
||||||
|
Communication protocol |
SMEMA |
||||||
