Features
1. Quick and easy to replace the screw/fluid cavity.
2. Separated fluid chamber component design.
3. Repeated accuracy, Precision and wear-resistant screw/fluid cavity.
4. Precise flow control, Adjustable flow rate.
5. Flexible needle barrel installation options.
Specifications
|
Model |
SV-06 |
|
Structure |
Quick release screw valve |
|
Dimensions (mm) |
57 * 109 * 278 |
|
Weight (g) |
320 |
|
Control mode |
Servo motor |
|
Glue delivery method |
Screw |
|
Applicable rubber cylinder size (cc) |
5, 10, 30, 50, 150 |
|
Optimum viscosity range (mPas) |
5000~1000000 |
|
Minimum dispensing volume (ul) |
0.5 |
|
Feed pressure (Mpa) |
0~0.4 |
|
Flow range (ul/min) |
1.38-60 |
|
Extrusion volume per turn (ul) |
1.38 |
